dots.ocr相關介紹

dots.ocr 是一個強大的多語言文檔解析器，它在一個單一的視覺-語言模型中統一了布局檢測和內容識別，同時保持良好的閱讀順序。盡管其基礎是緊湊的1.7B參數LLM，但它實現了最先進的（SOTA）性能。

強大的性能： dots.ocr 在OmniDocBench上實現了文本、表格和閱讀順序的SOTA性能，同時在公式識別方面達到了與Doubao-1.5和gemini2.5-pro等更大模型相當的結果。
多語言支持： dots.ocr 對低資源語言展示了強大的解析能力，在我們內部的多語言文檔基準測試中，在布局檢測和內容識別方面都取得了決定性的優勢。
統一且簡單的架構： 通過利用單一的視覺-語言模型，dots.ocr 提供了一個比依賴復雜多模型流水線的傳統方法更簡潔的架構。通過簡單地改變輸入提示即可在任務之間切換，證明VLM可以與傳統的檢測模型如DocLayout-YOLO相比達到有競爭力的檢測結果。
高效且快速的性能： 基于緊湊的1.7B LLM構建，dots.ocr 比許多基于更大基礎的高性能模型提供了更快的推理速度。

本地服務器端部署

項目先決條件：
該項目官方要求的pytroch為2.7、vllm為0.9.1，并且由于該項目依賴于flash-attn==2.8.0.post2，該包的編譯安裝依賴于cuda版本為12.8，所以，需要項目需要較新版本的英偉達顯卡驅動與CUDA12.8（要求是12.8）

第一步：安裝cuda12.8與CUDNN8.9.7

下載地址依次是：

https://developer.nvidia.com/cuda-12-8-0-download-archive?target_os=Linux&target_arch=x86_64&Distribution=Ubuntu&target_version=22.04&target_type=runfile_local

Ubutnu命令行運行如下指令：
下載cuda12.8

wget https://developer.download.nvidia.com/compute/cuda/12.8.0/local_installers/cuda_12.8.0_570.86.10_linux.run

安裝cuda12.8

# 賦予權限
chmod +x cuda_12.8.0_570.86.10_linux.run
# 執行安裝
./cuda_12.8.0_570.86.10_linux.run

修改~/.bashrc文件

vim ~/.bashrc

將如下內容添加到文件中

export CUDA_HOME=/usr/local/cuda-12.8
export PATH=$CUDA_HOME/bin:$PATH
export LD_LIBRARY_PATH=$CUDA_HOME/lib64:$LD_LIBRARY_PATH

修改完后，執行如下指令以生效：

 source ~/.bashrc

確保nvcc可以被找到

which nvcc
nvcc -V

下載cudnn8.9.7

https://developer.nvidia.com/rdp/cudnn-archive

# 解壓壓縮包文件
tar -xvf cudnn-linux-x86_64-8.9.7.29_cuda12-archive.tar.xz

拷貝文件并授權

cd cudnn-linux-x86_64-8.9.7.29_cuda12-archivesudo cp include/cudnn*.h /usr/local/cuda-12.8/include/
sudo cp lib/libcudnn* /usr/local/cuda-12.8/lib64/
sudo chmod a+r /usr/local/cuda-12.8/include/cudnn*.h /usr/local/cuda-12.8/lib64/libcudnn*

驗證是否成功

cat /usr/local/cuda/include/cudnn_version.h | grep CUDNN_MAJOR -A 2

第二步：創建項目所需的依賴環境

安裝好Miniconda后，執行如下指令創建虛擬環境

# 創建
conda create -n vllm_0_9_1 python=3.12
# 激活
conda activate vllm_0_9_1

下載項目代碼

git clone https://github.com/rednote-hilab/dots.ocr.git

安裝依賴庫

# 進入到項目目錄內
cd dots.ocr# 執行如下語句
pip install torch==2.7.0 torchvision==0.22.0 torchaudio==2.7.0 --index-url https://download.pytorch.org/whl/cu128   --default-timeout=100pip install vllm==0.9.1  --default-timeout=100 -i https://pypi.tuna.tsinghua.edu.cn/simplepip install -e .  --default-timeout=100 -i https://pypi.tuna.tsinghua.edu.cn/simple

模型下載
項目結構如下所示：

(vllm_0_9_1) root@d205d5131c12:/home/data/dots.ocr-master# tree -L 2
.
├── LICENSE
├── README.md
├── assets
│   ├── blog.md
│   ├── chart.png
│   ├── logo.png
│   ├── showcase
│   ├── showcase_origin
│   └── wechat.jpg
├── demo
│   ├── demo_gradio.py
│   ├── demo_gradio_annotion.py
│   ├── demo_hf.py
│   ├── demo_image1.jpg
│   ├── demo_pdf1.pdf
│   ├── demo_streamlit.py
│   ├── demo_vllm.py
│   └── launch_model_vllm.sh
├── docker
│   ├── Dockerfile
│   └── docker-compose.yml
├── dots_ocr
│   ├── __init__.py
│   ├── model
│   ├── parser.py
│   └── utils
├── dots_ocr.egg-info
│   ├── PKG-INFO
│   ├── SOURCES.txt
│   ├── dependency_links.txt
│   ├── requires.txt
│   └── top_level.txt
├── requirements.txt
├── setup.py
├── tools
│   └── download_model.py
└── weights└── DotsOCR12 directories, 26 files

在項目根目錄下執行如下指令下載模型：

python3 tools/download_model.py -t modelscope

第三步：啟動項目

以下啟動指令需要切換到項目根目錄下執行

export hf_model_path=./weights/DotsOCR  # Path to your downloaded model weights, Please use a directory name without periods (e.g., `DotsOCR` instead of `dots.ocr`) for the model save path. This is a temporary workaround pending our integration with Transformers.
export PYTHONPATH=$(dirname "$hf_model_path"):$PYTHONPATH
sed -i '/^from vllm\.entrypoints\.cli\.main import main$/a\
from DotsOCR import modeling_dots_ocr_vllm' `which vllm`  # If you downloaded model weights by yourself, please replace `DotsOCR` by your model saved directory name, and remember to use a directory name without periods (e.g., `DotsOCR` instead of `dots.ocr`) # launch vllm server# 單張顯卡
CUDA_VISIBLE_DEVICES=0 vllm serve ${hf_model_path} \--tensor-parallel-size 1 \--host 0.0.0.0     \--port 8070     \--gpu-memory-utilization 0.95 \--chat-template-content-format string \--served-model-name model \--trust-remote-code# If you get a ModuleNotFoundError: No module named 'DotsOCR', please check the note above on the saved model directory name.

項目順利啟動成功：

第四步：測試

上述vllm拉起項目后，便可運行官方自帶的測試腳本進行測試：
在dots.ocr-master/demo目錄下，有個名稱為demo_vllm.py的腳本，內容如下：

import argparse
import osfrom openai import OpenAI
from transformers.utils.versions import require_version
from PIL import Image
import io
import base64
from dots_ocr.utils import dict_promptmode_to_prompt
from dots_ocr.model.inference import inference_with_vllmparser = argparse.ArgumentParser()
parser.add_argument("--ip", type=str, default="localhost")
parser.add_argument("--port", type=str, default="8000")
parser.add_argument("--model_name", type=str, default="model")
parser.add_argument("--prompt_mode", type=str, default="prompt_layout_all_en")args = parser.parse_args()require_version("openai>=1.5.0", "To fix: pip install openai>=1.5.0")def main():addr = f"http://{args.ip}:{args.port}/v1"image_path = "demo/demo_image1.jpg"prompt = dict_promptmode_to_prompt[args.prompt_mode]image = Image.open(image_path)response = inference_with_vllm(image,prompt, ip="localhost",port=8000,temperature=0.1,top_p=0.9,)print(f"response: {response}")if __name__ == "__main__":main()

**注意：**如果在拉起vllm項目時修改了訪問ip與端口號后，直接運行上述腳本會報錯（原因是該腳本訪問ip與端口號被寫死）。
需要進行相應改動，修改完后的腳本如下：

import argparse
import osfrom openai import OpenAI
from transformers.utils.versions import require_version
from PIL import Image
import io
import base64
from dots_ocr.utils import dict_promptmode_to_prompt
from dots_ocr.model.inference import inference_with_vllmparser = argparse.ArgumentParser()
parser.add_argument("--ip", type=str, default="localhost")
parser.add_argument("--port", type=str, default="8070")
parser.add_argument("--model_name", type=str, default="model")
parser.add_argument("--prompt_mode", type=str, default="prompt_layout_all_en")args = parser.parse_args()require_version("openai>=1.5.0", "To fix: pip install openai>=1.5.0")def main():addr = f"http://{args.ip}:{args.port}/v1"image_path = "demo/demo_image1.jpg"prompt = dict_promptmode_to_prompt[args.prompt_mode]image = Image.open(image_path)response = inference_with_vllm(image,prompt, ip=args.ip,port=int(args.port),temperature=0.1,top_p=0.9,)print(f"response: {response}")if __name__ == "__main__":main()

然后直接運行下屬指令便可返回識別結果

python3 ./demo/demo_vllm.py --prompt_mode prompt_layout_all_en --ip 192.168.4.22 --port 8070

第五步：文本解析相關性測試

進入到dots.ocr-master/dots_ocr目錄下，有個名為parser.py的文件，可以提供如下測試：
針對圖像或 PDF 文件進行 版面分析（Layout Parsing）和文字識別（OCR）。每條命令根據不同的參數控制功能側重。下面是詳細解釋：

# 基礎命令：同時做版面檢測 + OCR#對一張圖片進行：#版面分析（如識別段落、標題、表格、圖片區域等布局結構）#OCR 識別（提取其中的文字內容）
python3 dots_ocr/parser.py demo/demo_image1.jpg# -------------------------------------------------------------# 對一個 PDF 文件進行版面檢測和 OCR。# 額外加了 --num_thread 64，說明：# 多線程解析 PDF 的每一頁（尤其是多頁 PDF），提高處理速度# 可以嘗試更高線程數（如 --num_thread 128）以加速大文檔處理
python3 dots_ocr/parser.py demo/demo_pdf1.pdf  --num_thread 64  # try bigger num_threads for pdf with a large number of pages# 只做版面分析（不提取文字）
python3 dots_ocr/parser.py demo/demo_image1.jpg --prompt prompt_layout_only_en# 只做 OCR，不提取頁眉頁腳的文字 Parse text only, except Page-header and Page-footer
python3 dots_ocr/parser.py demo/demo_image1.jpg --prompt prompt_ocr#  對指定區域（bounding box）做 OCR+Layout 分析 Parse layout info by bbox
python3 dots_ocr/parser.py demo/demo_image1.jpg --prompt prompt_grounding_ocr --bbox 163 241 1536 705

如果上述vllm在啟動模型時配置了相關的ip與端口，則在啟動時需要加上–ip與–port
如下所示：

python3 dots_ocr/parser.py demo/demo_pdf1.pdf  --num_thread 64  --ip 192.168.4.22 --port 8070

腳本代碼如下所示：

import os
import json
from tqdm import tqdm
from multiprocessing.pool import ThreadPool, Pool
import argparsefrom dots_ocr.model.inference import inference_with_vllm
from dots_ocr.utils.consts import image_extensions, MIN_PIXELS, MAX_PIXELS
from dots_ocr.utils.image_utils import get_image_by_fitz_doc, fetch_image, smart_resize
from dots_ocr.utils.doc_utils import fitz_doc_to_image, load_images_from_pdf
from dots_ocr.utils.prompts import dict_promptmode_to_prompt
from dots_ocr.utils.layout_utils import post_process_output, draw_layout_on_image, pre_process_bboxes
from dots_ocr.utils.format_transformer import layoutjson2mdclass DotsOCRParser:"""parse image or pdf file"""def __init__(self, ip='localhost',port=8000,model_name='model',temperature=0.1,top_p=1.0,max_completion_tokens=16384,num_thread=64,dpi = 200, output_dir="./output", min_pixels=None,max_pixels=None,):self.dpi = dpi# default args for vllm serverself.ip = ipself.port = portself.model_name = model_name# default args for inferenceself.temperature = temperatureself.top_p = top_pself.max_completion_tokens = max_completion_tokensself.num_thread = num_threadself.output_dir = output_dirself.min_pixels = min_pixelsself.max_pixels = max_pixelsassert self.min_pixels is None or self.min_pixels >= MIN_PIXELSassert self.max_pixels is None or self.max_pixels <= MAX_PIXELSdef _inference_with_vllm(self, image, prompt):response = inference_with_vllm(image,prompt, model_name=self.model_name,ip=self.ip,port=self.port,temperature=self.temperature,top_p=self.top_p,max_completion_tokens=self.max_completion_tokens,)return responsedef get_prompt(self, prompt_mode, bbox=None, origin_image=None, image=None, min_pixels=None, max_pixels=None):prompt = dict_promptmode_to_prompt[prompt_mode]if prompt_mode == 'prompt_grounding_ocr':assert bbox is not Nonebboxes = [bbox]bbox = pre_process_bboxes(origin_image, bboxes, input_width=image.width, input_height=image.height, min_pixels=min_pixels, max_pixels=max_pixels)[0]prompt = prompt + str(bbox)return prompt# def post_process_results(self, response, prompt_mode, save_dir, save_name, origin_image, image, min_pixels, max_pixels)def _parse_single_image(self, origin_image, prompt_mode, save_dir, save_name, source="image", page_idx=0, bbox=None,fitz_preprocess=False,):min_pixels, max_pixels = self.min_pixels, self.max_pixelsif prompt_mode == "prompt_grounding_ocr":min_pixels = min_pixels or MIN_PIXELS  # preprocess image to the final inputmax_pixels = max_pixels or MAX_PIXELSif min_pixels is not None: assert min_pixels >= MIN_PIXELS, f"min_pixels should >= {MIN_PIXELS}"if max_pixels is not None: assert max_pixels <= MAX_PIXELS, f"max_pixels should <+ {MAX_PIXELS}"if source == 'image' and fitz_preprocess:image = get_image_by_fitz_doc(origin_image, target_dpi=self.dpi)image = fetch_image(image, min_pixels=min_pixels, max_pixels=max_pixels)else:image = fetch_image(origin_image, min_pixels=min_pixels, max_pixels=max_pixels)input_height, input_width = smart_resize(image.height, image.width)prompt = self.get_prompt(prompt_mode, bbox, origin_image, image, min_pixels=min_pixels, max_pixels=max_pixels)response = self._inference_with_vllm(image, prompt)result = {'page_no': page_idx,"input_height": input_height,"input_width": input_width}if source == 'pdf':save_name = f"{save_name}_page_{page_idx}"if prompt_mode in ['prompt_layout_all_en', 'prompt_layout_only_en', 'prompt_grounding_ocr']:cells, filtered = post_process_output(response, prompt_mode, origin_image, image,min_pixels=min_pixels, max_pixels=max_pixels,)if filtered and prompt_mode != 'prompt_layout_only_en':  # model output json failed, use filtered processjson_file_path = os.path.join(save_dir, f"{save_name}.json")with open(json_file_path, 'w') as w:json.dump(response, w, ensure_ascii=False)image_layout_path = os.path.join(save_dir, f"{save_name}.jpg")origin_image.save(image_layout_path)result.update({'layout_info_path': json_file_path,'layout_image_path': image_layout_path,})md_file_path = os.path.join(save_dir, f"{save_name}.md")with open(md_file_path, "w", encoding="utf-8") as md_file:md_file.write(cells)result.update({'md_content_path': md_file_path})result.update({'filtered': True})else:try:image_with_layout = draw_layout_on_image(origin_image, cells)except Exception as e:print(f"Error drawing layout on image: {e}")image_with_layout = origin_imagejson_file_path = os.path.join(save_dir, f"{save_name}.json")with open(json_file_path, 'w') as w:json.dump(cells, w, ensure_ascii=False)image_layout_path = os.path.join(save_dir, f"{save_name}.jpg")image_with_layout.save(image_layout_path)result.update({'layout_info_path': json_file_path,'layout_image_path': image_layout_path,})if prompt_mode != "prompt_layout_only_en":  # no text md when detection onlymd_content = layoutjson2md(origin_image, cells, text_key='text')md_content_no_hf = layoutjson2md(origin_image, cells, text_key='text', no_page_hf=True) # used for clean output or metric of omnidocbench、olmbench md_file_path = os.path.join(save_dir, f"{save_name}.md")with open(md_file_path, "w", encoding="utf-8") as md_file:md_file.write(md_content)md_nohf_file_path = os.path.join(save_dir, f"{save_name}_nohf.md")with open(md_nohf_file_path, "w", encoding="utf-8") as md_file:md_file.write(md_content_no_hf)result.update({'md_content_path': md_file_path,'md_content_nohf_path': md_nohf_file_path,})else:image_layout_path = os.path.join(save_dir, f"{save_name}.jpg")origin_image.save(image_layout_path)result.update({'layout_image_path': image_layout_path,})md_content = responsemd_file_path = os.path.join(save_dir, f"{save_name}.md")with open(md_file_path, "w", encoding="utf-8") as md_file:md_file.write(md_content)result.update({'md_content_path': md_file_path,})return resultdef parse_image(self, input_path, filename, prompt_mode, save_dir, bbox=None, fitz_preprocess=False):origin_image = fetch_image(input_path)result = self._parse_single_image(origin_image, prompt_mode, save_dir, filename, source="image", bbox=bbox, fitz_preprocess=fitz_preprocess)result['file_path'] = input_pathreturn [result]def parse_pdf(self, input_path, filename, prompt_mode, save_dir):print(f"loading pdf: {input_path}")images_origin = load_images_from_pdf(input_path, dpi=self.dpi)total_pages = len(images_origin)tasks = [{"origin_image": image,"prompt_mode": prompt_mode,"save_dir": save_dir,"save_name": filename,"source":"pdf","page_idx": i,} for i, image in enumerate(images_origin)]def _execute_task(task_args):return self._parse_single_image(**task_args)num_thread = min(total_pages, self.num_thread)print(f"Parsing PDF with {total_pages} pages using {num_thread} threads...")results = []with ThreadPool(num_thread) as pool:with tqdm(total=total_pages, desc="Processing PDF pages") as pbar:for result in pool.imap_unordered(_execute_task, tasks):results.append(result)pbar.update(1)results.sort(key=lambda x: x["page_no"])for i in range(len(results)):results[i]['file_path'] = input_pathreturn resultsdef parse_file(self, input_path, output_dir="", prompt_mode="prompt_layout_all_en",bbox=None,fitz_preprocess=False):output_dir = output_dir or self.output_diroutput_dir = os.path.abspath(output_dir)filename, file_ext = os.path.splitext(os.path.basename(input_path))save_dir = os.path.join(output_dir, filename)os.makedirs(save_dir, exist_ok=True)if file_ext == '.pdf':results = self.parse_pdf(input_path, filename, prompt_mode, save_dir)elif file_ext in image_extensions:results = self.parse_image(input_path, filename, prompt_mode, save_dir, bbox=bbox, fitz_preprocess=fitz_preprocess)else:raise ValueError(f"file extension {file_ext} not supported, supported extensions are {image_extensions} and pdf")print(f"Parsing finished, results saving to {save_dir}")with open(os.path.join(output_dir, os.path.basename(filename)+'.jsonl'), 'w') as w:for result in results:w.write(json.dumps(result, ensure_ascii=False) + '\n')return resultsdef main():prompts = list(dict_promptmode_to_prompt.keys())parser = argparse.ArgumentParser(description="dots.ocr Multilingual Document Layout Parser",)parser.add_argument("input_path", type=str,help="Input PDF/image file path")parser.add_argument("--output", type=str, default="./output",help="Output directory (default: ./output)")parser.add_argument("--prompt", choices=prompts, type=str, default="prompt_layout_all_en",help="prompt to query the model, different prompts for different tasks")parser.add_argument('--bbox', type=int, nargs=4, metavar=('x1', 'y1', 'x2', 'y2'),help='should give this argument if you want to prompt_grounding_ocr')parser.add_argument("--ip", type=str, default="localhost",help="")parser.add_argument("--port", type=int, default=8000,help="")parser.add_argument("--model_name", type=str, default="model",help="")parser.add_argument("--temperature", type=float, default=0.1,help="")parser.add_argument("--top_p", type=float, default=1.0,help="")parser.add_argument("--dpi", type=int, default=200,help="")parser.add_argument("--max_completion_tokens", type=int, default=16384,help="")parser.add_argument("--num_thread", type=int, default=16,help="")# parser.add_argument(#     "--fitz_preprocess", type=bool, default=False,#     help="False will use tikz dpi upsample pipeline, good for images which has been render with low dpi, but maybe result in higher computational costs"# )parser.add_argument("--min_pixels", type=int, default=None,help="")parser.add_argument("--max_pixels", type=int, default=None,help="")args = parser.parse_args()dots_ocr_parser = DotsOCRParser(ip=args.ip,port=args.port,model_name=args.model_name,temperature=args.temperature,top_p=args.top_p,max_completion_tokens=args.max_completion_tokens,num_thread=args.num_thread,dpi=args.dpi,output_dir=args.output, min_pixels=args.min_pixels,max_pixels=args.max_pixels,)result = dots_ocr_parser.parse_file(args.input_path, prompt_mode=args.prompt,bbox=args.bbox,)if __name__ == "__main__":main()

輸出結果

• 結構化布局數據 (demo_image1.json)：包含檢測到的布局元素（包括它們的邊界框、類別和提取的文本）的 JSON 文件。
• 處理后的 Markdown 文件 (demo_image1.md)：從所有檢測到的單元格拼接文本生成的 Markdown 文件。

另提供了一個版本 demo_image1_nohf.md，它排除了頁面頭部和底部，以兼容如 Omnidocbench 和 olmOCR-bench 等基準測試。

• 布局可視化 (demo_image1.jpg)：原始圖像上繪制了檢測到的布局邊界框。

第六步：利用gradio部署服務項目

思路是：vllm已經加載模型啟動項目，使用gradio啟動一個服務，訪問vllm加載的模型，返回識別結果
在dots.ocr-master/demo目錄下，修改demo_gradio.py文件，配置成vllm項目的ip與端口，如下所示

執行如下指令啟動gradio服務

python demo/demo_gradio.py

腳本代碼：

"""
Layout Inference Web Application with GradioA Gradio-based layout inference tool that supports image uploads and multiple backend inference engines.
It adopts a reference-style interface design while preserving the original inference logic.
"""import gradio as gr
import json
import os
import io
import tempfile
import base64
import zipfile
import uuid
import re
from pathlib import Path
from PIL import Image
import requests# Local tool imports
from dots_ocr.utils import dict_promptmode_to_prompt
from dots_ocr.utils.consts import MIN_PIXELS, MAX_PIXELS
from dots_ocr.utils.demo_utils.display import read_image
from dots_ocr.utils.doc_utils import load_images_from_pdf# Add DotsOCRParser import
from dots_ocr.parser import DotsOCRParser# ==================== Configuration ====================
DEFAULT_CONFIG = {'ip': "192.168.4.22",'port_vllm': 8070,'min_pixels': MIN_PIXELS,'max_pixels': MAX_PIXELS,'test_images_dir': "./assets/showcase_origin",
}# ==================== Global Variables ====================
# Store current configuration
current_config = DEFAULT_CONFIG.copy()# Create DotsOCRParser instance
dots_parser = DotsOCRParser(ip=DEFAULT_CONFIG['ip'],port=DEFAULT_CONFIG['port_vllm'],dpi=200,min_pixels=DEFAULT_CONFIG['min_pixels'],max_pixels=DEFAULT_CONFIG['max_pixels']
)# Store processing results
processing_results = {'original_image': None,'processed_image': None,'layout_result': None,'markdown_content': None,'cells_data': None,'temp_dir': None,'session_id': None,'result_paths': None,'pdf_results': None  # Store multi-page PDF results
}# PDF caching mechanism
pdf_cache = {"images": [],"current_page": 0,"total_pages": 0,"file_type": None,  # 'image' or 'pdf'"is_parsed": False,  # Whether it has been parsed"results": []  # Store parsing results for each page
def process_image_inference(test_image_input, file_input,prompt_mode, server_ip, server_port, min_pixels, max_pixels,fitz_preprocess=False):"""Core function to handle image/PDF inference"""global current_config, processing_results, dots_parser, pdf_cache# First, clean up previous processing results to avoid confusion with the download buttonif processing_results.get('temp_dir') and os.path.exists(processing_results['temp_dir']):import shutiltry:shutil.rmtree(processing_results['temp_dir'], ignore_errors=True)except Exception as e:print(f"Failed to clean up previous temporary directory: {e}")# Reset processing resultsprocessing_results = {'original_image': None,'processed_image': None,'layout_result': None,'markdown_content': None,'cells_data': None,'temp_dir': None,'session_id': None,'result_paths': None,'pdf_results': None}# Update configurationcurrent_config.update({'ip': server_ip,'port_vllm': server_port,'min_pixels': min_pixels,'max_pixels': max_pixels})# Update parser configurationdots_parser.ip = server_ipdots_parser.port = server_portdots_parser.min_pixels = min_pixelsdots_parser.max_pixels = max_pixels# Determine the input sourceinput_file_path = Noneimage = None# Prioritize file input (supports PDF)if file_input is not None:input_file_path = file_inputfile_ext = os.path.splitext(input_file_path)[1].lower()if file_ext == '.pdf':# PDF file processingtry:return process_pdf_file(input_file_path, prompt_mode)except Exception as e:return None, f"PDF processing failed: {e}", "", "", gr.update(value=None), None, ""elif file_ext in ['.jpg', '.jpeg', '.png']:# Image file processingtry:image = Image.open(input_file_path)except Exception as e:return None, f"Failed to read image file: {e}", "", "", gr.update(value=None), None, ""# If no file input, check the test image inputif image is None:if test_image_input and test_image_input != "":file_ext = os.path.splitext(test_image_input)[1].lower()if file_ext == '.pdf':return process_pdf_file(test_image_input, prompt_mode)else:try:image = read_image_v2(test_image_input)except Exception as e:return None, f"Failed to read test image: {e}", "", "", gr.update(value=None), gr.update(value=None), None, ""if image is None:return None, "Please upload image/PDF file or select test image", "", "", gr.update(value=None), None, ""try:# Clear PDF cache (for image processing)pdf_cache["images"] = []pdf_cache["current_page"] = 0pdf_cache["total_pages"] = 0pdf_cache["is_parsed"] = Falsepdf_cache["results"] = []# Process using the high-level API of DotsOCRParseroriginal_image = imageparse_result = parse_image_with_high_level_api(dots_parser, image, prompt_mode, fitz_preprocess)# Extract parsing resultslayout_image = parse_result['layout_image']cells_data = parse_result['cells_data']md_content = parse_result['md_content']filtered = parse_result['filtered']# Handle parsing failure caseif filtered:# JSON parsing failed, only text content is availableinfo_text = f"""
**Image Information:**
- Original Size: {original_image.width} x {original_image.height}
- Processing: JSON parsing failed, using cleaned text output
- Server: {current_config['ip']}:{current_config['port_vllm']}
- Session ID: {parse_result['session_id']}"""# Store resultsprocessing_results.update({'original_image': original_image,'processed_image': None,'layout_result': None,'markdown_content': md_content,'cells_data': None,'temp_dir': parse_result['temp_dir'],'session_id': parse_result['session_id'],'result_paths': parse_result['result_paths']})return (original_image,  # No layout imageinfo_text,md_content,md_content,  # Display raw markdown textgr.update(visible=False),  # Hide download buttonNone,  # Page info""     # Current page JSON output)# JSON parsing successful case# Save the raw markdown content (before LaTeX processing)md_content_raw = md_content or "No markdown content generated"# Store resultsprocessing_results.update({'original_image': original_image,'processed_image': None,  # High-level API does not return processed_image'layout_result': layout_image,'markdown_content': md_content,'cells_data': cells_data,'temp_dir': parse_result['temp_dir'],'session_id': parse_result['session_id'],'result_paths': parse_result['result_paths']})# Prepare display informationnum_elements = len(cells_data) if cells_data else 0info_text = f"""
**Image Information:**
- Original Size: {original_image.width} x {original_image.height}
- Model Input Size: {parse_result['input_width']} x {parse_result['input_height']}
- Server: {current_config['ip']}:{current_config['port_vllm']}
- Detected {num_elements} layout elements
- Session ID: {parse_result['session_id']}"""# Current page JSON outputcurrent_json = ""if cells_data:try:current_json = json.dumps(cells_data, ensure_ascii=False, indent=2)except:current_json = str(cells_data)# Create the download ZIP filedownload_zip_path = Noneif parse_result['temp_dir']:download_zip_path = os.path.join(parse_result['temp_dir'], f"layout_results_{parse_result['session_id']}.zip")try:with zipfile.ZipFile(download_zip_path, 'w', zipfile.ZIP_DEFLATED) as zipf:for root, dirs, files in os.walk(parse_result['temp_dir']):for file in files:if file.endswith('.zip'):continuefile_path = os.path.join(root, file)arcname = os.path.relpath(file_path, parse_result['temp_dir'])zipf.write(file_path, arcname)except Exception as e:print(f"Failed to create download ZIP: {e}")download_zip_path = Nonereturn (layout_image,info_text,md_content or "No markdown content generated",md_content_raw,  # Raw markdown textgr.update(value=download_zip_path, visible=True) if download_zip_path else gr.update(visible=False),  # Set the download fileNone,  # Page info (not displayed for image processing)current_json     # Current page JSON)except Exception as e:return None, f"Error during processing: {e}", "", "", gr.update(value=None), None, ""def process_pdf_file(pdf_path, prompt_mode):"""Dedicated function for processing PDF files"""global pdf_cache, processing_results, dots_parsertry:# First, load the PDF for previewpreview_image, page_info = load_file_for_preview(pdf_path)# Parse the PDF using DotsOCRParserpdf_result = parse_pdf_with_high_level_api(dots_parser, pdf_path, prompt_mode)# Update the PDF cachepdf_cache["is_parsed"] = Truepdf_cache["results"] = pdf_result['parsed_results']# Handle LaTeX table renderingcombined_md = pdf_result['combined_md_content']combined_md_raw = combined_md or "No markdown content generated"  # Save the raw content# Store resultsprocessing_results.update({'original_image': None,'processed_image': None,'layout_result': None,'markdown_content': combined_md,'cells_data': pdf_result['combined_cells_data'],'temp_dir': pdf_result['temp_dir'],'session_id': pdf_result['session_id'],'result_paths': None,'pdf_results': pdf_result['parsed_results']})# Prepare display informationtotal_elements = len(pdf_result['combined_cells_data'])info_text = f"""
**PDF Information:**
- Total Pages: {pdf_result['total_pages']}
- Server: {current_config['ip']}:{current_config['port_vllm']}
- Total Detected Elements: {total_elements}
- Session ID: {pdf_result['session_id']}"""# Content of the current page (first page)current_page_md = ""current_page_md_raw = ""current_page_json = ""current_page_layout_image = preview_image  # Use the original preview image by defaultif pdf_cache["results"] and len(pdf_cache["results"]) > 0:current_result = pdf_cache["results"][0]if current_result['md_content']:# Raw markdown contentcurrent_page_md_raw = current_result['md_content']# Process the content after LaTeX renderingcurrent_page_md = current_result['md_content']if current_result['cells_data']:try:current_page_json = json.dumps(current_result['cells_data'], ensure_ascii=False, indent=2)except:current_page_json = str(current_result['cells_data'])# Use the image with layout boxes (if available)if 'layout_image' in current_result and current_result['layout_image']:current_page_layout_image = current_result['layout_image']# Create the download ZIP filedownload_zip_path = Noneif pdf_result['temp_dir']:download_zip_path = os.path.join(pdf_result['temp_dir'], f"layout_results_{pdf_result['session_id']}.zip")try:with zipfile.ZipFile(download_zip_path, 'w', zipfile.ZIP_DEFLATED) as zipf:for root, dirs, files in os.walk(pdf_result['temp_dir']):for file in files:if file.endswith('.zip'):continuefile_path = os.path.join(root, file)arcname = os.path.relpath(file_path, pdf_result['temp_dir'])zipf.write(file_path, arcname)except Exception as e:print(f"Failed to create download ZIP: {e}")download_zip_path = Nonereturn (current_page_layout_image,  # Use the image with layout boxesinfo_text,combined_md or "No markdown content generated",  # Display the markdown for the entire PDFcombined_md_raw or "No markdown content generated",  # Display the raw markdown for the entire PDFgr.update(value=download_zip_path, visible=True) if download_zip_path else gr.update(visible=False),  # Set the download filepage_info,current_page_json)except Exception as e:# Reset the PDF cachepdf_cache["images"] = []pdf_cache["current_page"] = 0pdf_cache["total_pages"] = 0pdf_cache["is_parsed"] = Falsepdf_cache["results"] = []raise edef clear_all_data():"""Clears all data"""global processing_results, pdf_cache# Clean up the temporary directoryif processing_results.get('temp_dir') and os.path.exists(processing_results['temp_dir']):import shutiltry:shutil.rmtree(processing_results['temp_dir'], ignore_errors=True)except Exception as e:print(f"Failed to clean up temporary directory: {e}")# Reset processing resultsprocessing_results = {'original_image': None,'processed_image': None,'layout_result': None,'markdown_content': None,'cells_data': None,'temp_dir': None,'session_id': None,'result_paths': None,'pdf_results': None}# Reset the PDF cachepdf_cache = {"images": [],"current_page": 0,"total_pages": 0,"file_type": None,"is_parsed": False,"results": []}return (None,  # Clear file input"",    # Clear test image selectionNone,  # Clear result image"Waiting for processing results...",  # Reset info display"## Waiting for processing results...",  # Reset Markdown display"馃晲 Waiting for parsing result...",    # Clear raw Markdown textgr.update(visible=False),  # Hide download button"<div id='page_info_box'>0 / 0</div>",  # Reset page info"馃晲 Waiting for parsing result..."     # Clear current page JSON)def update_prompt_display(prompt_mode):"""Updates the prompt display content"""return dict_promptmode_to_prompt[prompt_mode]# ==================== Gradio Interface ====================
def create_gradio_interface():"""Creates the Gradio interface"""# CSS styles, matching the reference stylecss = """#parse_button {background: #FF576D !important; /* !important 紜繚瑕嗙洊涓婚榛樿鏍峰紡 */border-color: #FF576D !important;}/* 榧犳爣鎮仠鏃剁殑棰滆壊 */#parse_button:hover {background: #F72C49 !important;border-color: #F72C49 !important;}#page_info_html {display: flex;align-items: center;justify-content: center;height: 100%;margin: 0 12px;}#page_info_box {padding: 8px 20px;font-size: 16px;border: 1px solid #bbb;border-radius: 8px;background-color: #f8f8f8;text-align: center;min-width: 80px;box-shadow: 0 1px 3px rgba(0,0,0,0.1);}#markdown_output {min-height: 800px;overflow: auto;}footer {visibility: hidden;}#info_box {padding: 10px;background-color: #f8f9fa;border-radius: 8px;border: 1px solid #dee2e6;margin: 10px 0;font-size: 14px;}#result_image {border-radius: 8px;}#markdown_tabs {height: 100%;}"""with gr.Blocks(theme="ocean", css=css, title='dots.ocr') as demo:# Titlegr.HTML("""<div style="display: flex; align-items: center; justify-content: center; margin-bottom: 20px;"><h1 style="margin: 0; font-size: 2em;">馃攳 dots.ocr</h1></div><div style="text-align: center; margin-bottom: 10px;"><em>Supports image/PDF layout analysis and structured output</em></div>""")with gr.Row():# Left side: Input and Configurationwith gr.Column(scale=1, elem_id="left-panel"):gr.Markdown("### 馃摜 Upload & Select")file_input = gr.File(label="Upload PDF/Image", type="filepath", file_types=[".pdf", ".jpg", ".jpeg", ".png"],)test_images = get_test_images()test_image_input = gr.Dropdown(label="Or Select an Example",choices=[""] + test_images,value="",)gr.Markdown("### 鈿欙笍 Prompt & Actions")prompt_mode = gr.Dropdown(label="Select Prompt",choices=["prompt_layout_all_en", "prompt_layout_only_en", "prompt_ocr"],value="prompt_layout_all_en",show_label=True)# Display current prompt contentprompt_display = gr.Textbox(label="Current Prompt Content",value=dict_promptmode_to_prompt[list(dict_promptmode_to_prompt.keys())[0]],lines=4,max_lines=8,interactive=False,show_copy_button=True)with gr.Row():process_btn = gr.Button("馃攳 Parse", variant="primary", scale=2, elem_id="parse_button")clear_btn = gr.Button("馃棏鋦?Clear", variant="secondary", scale=1)with gr.Accordion("馃洜鋦?Advanced Configuration", open=False):fitz_preprocess = gr.Checkbox(label="Enable fitz_preprocess for images", value=True,info="Processes image via a PDF-like pipeline (image->pdf->200dpi image). Recommended if your image DPI is low.")with gr.Row():server_ip = gr.Textbox(label="Server IP", value=DEFAULT_CONFIG['ip'])server_port = gr.Number(label="Port", value=DEFAULT_CONFIG['port_vllm'], precision=0)with gr.Row():min_pixels = gr.Number(label="Min Pixels", value=DEFAULT_CONFIG['min_pixels'], precision=0)max_pixels = gr.Number(label="Max Pixels", value=DEFAULT_CONFIG['max_pixels'], precision=0)# Right side: Result Displaywith gr.Column(scale=6, variant="compact"):with gr.Row():# Result Imagewith gr.Column(scale=3):gr.Markdown("### 馃憗鋦?File Preview")result_image = gr.Image(label="Layout Preview",visible=True,height=800,show_label=False)# Page navigation (shown during PDF preview)with gr.Row():prev_btn = gr.Button("猬?Previous", size="sm")page_info = gr.HTML(value="<div id='page_info_box'>0 / 0</div>", elem_id="page_info_html")next_btn = gr.Button("Next 鉃?, size="sm")# Info Displayinfo_display = gr.Markdown("Waiting for processing results...",elem_id="info_box")# Markdown Resultwith gr.Column(scale=3):gr.Markdown("### 鉁旓笍 Result Display")with gr.Tabs(elem_id="markdown_tabs"):with gr.TabItem("Markdown Render Preview"):md_output = gr.Markdown("## Please click the parse button to parse or select for single-task recognition...",label="Markdown Preview",max_height=600,latex_delimiters=[{"left": "$$", "right": "$$", "display": True},{"left": "$", "right": "$", "display": False},],show_copy_button=False,elem_id="markdown_output")with gr.TabItem("Markdown Raw Text"):md_raw_output = gr.Textbox(value="馃晲 Waiting for parsing result...",label="Markdown Raw Text",max_lines=100,lines=38,show_copy_button=True,elem_id="markdown_output",show_label=False)with gr.TabItem("Current Page JSON"):current_page_json = gr.Textbox(value="馃晲 Waiting for parsing result...",label="Current Page JSON",max_lines=100,lines=38,show_copy_button=True,elem_id="markdown_output",show_label=False)# Download Buttonwith gr.Row():download_btn = gr.DownloadButton("猬囷笍 Download Results",visible=False)# When the prompt mode changes, update the display contentprompt_mode.change(fn=update_prompt_display,inputs=prompt_mode,outputs=prompt_display,show_progress=False)# Show preview on file uploadfile_input.upload(fn=load_file_for_preview,inputs=file_input,outputs=[result_image, page_info],show_progress=False)# Page navigationprev_btn.click(fn=lambda: turn_page("prev"), outputs=[result_image, page_info, current_page_json],show_progress=False)next_btn.click(fn=lambda: turn_page("next"), outputs=[result_image, page_info, current_page_json],show_progress=False)process_btn.click(fn=process_image_inference,inputs=[test_image_input, file_input,prompt_mode, server_ip, server_port, min_pixels, max_pixels, fitz_preprocess],outputs=[result_image, info_display, md_output, md_raw_output,download_btn, page_info, current_page_json],show_progress=True)clear_btn.click(fn=clear_all_data,outputs=[file_input, test_image_input,result_image, info_display, md_output, md_raw_output,download_btn, page_info, current_page_json],show_progress=False)return demo# ==================== Main Program ====================
if __name__ == "__main__":demo = create_gradio_interface()demo.queue().launch(server_name="0.0.0.0", server_port=8091, debug=True)
